TT Electronics / Welwyn WDBR2-150RKT Through Hole Resistor 150 ohm Wdbr 2 kW ± 10% 2.5 kV

The Welwyn WDBR2 Series are ultra low profile thick film power resistors. These resistors are single fixing heat sink mountable and ideal for dynamic braking, inrush limit and snubber circuits. Resistor terminals available with options of solder pad, flying leads and push-on connectors. WDBR2 Series has low inductance and high isolation even after failsafe overload fusing.

• Resistance value range from 12, 15, 20, 22, 25, 47, 50, 100 and 150 ohm
• ±10% tolerance
• Pulse power rating of 2kW
• Power rating on heat sink is 200W
• Operating temperature (element) of 365°C
• Temperature coefficient is resistor (TCR) range from +500 to +600ppm/°C
• High Power Resistor

Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Other details

Brand	TT ELECTRONICS / WELWYN
Part Number	WDBR2-150RKT
Quantity	Each
Technical Data Sheet EN
Product Change Notice EN
