Monolithic Power Systems (MPS) MPQ4590GS-Z MPQ4590GS-Z DC/DC Switching Regulator Fixed Boost Buck-Boost Flyback 5.3V to 5.6V in 400mA Out SOIC-8

• 640V non-isolated regulator up to 400mA output current
• Primary-side CV control, supporting buck, boost, buck-boost and flyback topologies
• Less than 30mW no-load power consumption
• Up to 5W output power
• Maximum DCM output current less than 250mA and maximum CCM output current less than 400mA
• Low VCC operating current
• Frequency foldback
• Peak current compression
• Internally biased VCC
• OTP, UVLO, OLP, SCP, open-loop protection

Footnotes MPS part numbers ending in "-P" and "-Z" are the same parts. P & Z only indicates reel size. Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Other details

Brand	MONOLITHIC POWER SYSTEMS (MPS)
Part Number	MPQ4590GS-Z
Quantity	Each (Supplied on Cut Tape)
Technical Data Sheet EN
