Phoenix Contact MSTB 25/16-STF-508 MSTB 25/16-STF-508 Pluggable Terminal Block 5.08 mm 16 Ways 24AWG to 12AWG 2.5 mm² Screw 12 A
Phoenix Contact MSTB 25/16-STF-508 MSTB 25/16-STF-508 Pluggable Terminal Block 5.08 mm 16 Ways 24AWG to 12AWG 2.5 mm² Screw 12 A
- Nominal current is 12A
- Rated voltage (III/3) is 250V, (III/2) is 320V, (II/2) is 630V
- Green colour polyamide insulating material
- Connection capacity is 0.2mm² to 2.5mm² (solid), 0.2mm² to 2.5mm² (stranded)
- Flammability rating according to UL 94 V0
- Screwable flange for superior mechanical stability
- Contract surface is tin
Industrial
Other details
| Brand | PHOENIX CONTACT |
| Part Number | MSTB 2,5/16-STF-5,08 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Original: $19.50
-70%$19.50
$5.85Phoenix Contact MSTB 25/16-STF-508 MSTB 25/16-STF-508 Pluggable Terminal Block 5.08 mm 16 Ways 24AWG to 12AWG 2.5 mm² Screw 12 A
- Nominal current is 12A
- Rated voltage (III/3) is 250V, (III/2) is 320V, (II/2) is 630V
- Green colour polyamide insulating material
- Connection capacity is 0.2mm² to 2.5mm² (solid), 0.2mm² to 2.5mm² (stranded)
- Flammability rating according to UL 94 V0
- Screwable flange for superior mechanical stability
- Contract surface is tin
Industrial
Other details
| Brand | PHOENIX CONTACT |
| Part Number | MSTB 2,5/16-STF-5,08 |
| Quantity | Each |
| Technical Data Sheet EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
