Bogen Communications AFI-8 Contractor Series Wide-Angled Loudspeaker System (White)
The white AFI-8 Contractor Series Wide-Angled Loudspeaker System from Bogen Communications is capable of filling large churches, theaters, sports venues, and theme parks with clean, articulate, full bandwidth sound. This loudspeaker system is available with a 90 x 40� high-frequency horn pattern, insuring that the AFI-8 works efficiently in any room configuration.
- Low Frequency
- One Apogee 15" (381mm) permanent magnet conetype driver is treated with a waterproofing compound, providing resistance to moisture, and enabling long-term stability of cone resonance and cone mass parameters; also treated with Ferrofluid for greater power handling capability, lower distortion, and control of short-term impedance rise
- High Frequency
- One Apogee 3" (76mm) voice coil, 2" (51mm) exit horn-loaded compression driver treated with Ferrofluid for efficient power handling capability, lower distortion, and control of shortterm impedance rise
- Input Connectors
- Barrier strip, screw type #8
- Compatible Processors
- AFI Main Frame Controller Chassis or DLC24
- Handles
- Two handles - one top, one bottom - designed as an integral part of the enclosure (no moving parts)
- Grille
- Highly durable, quality finish on perforated steel
- Rigging Hardware
- Fourteen rigging points, four each on top and bottom, two each on both sides and rear, all backed with 16-gauge steel; points can be type 3/8"-16 or M10 thread
- Finish
- Textured high-strength white epoxy paint
- Enclosure Type
- 30� trapezoidal, optimally-vented bass
- Cabinet Construction
- Multi-ply hardwood
In the Box
Bogen Communications AFI-8 Contractor Series Wide-Angled Loudspeaker System (White)
- Limited 2-Year Warranty
| Configuration | Passive Two-way |
| Dispersion | 90 x 40� |
| Frequency Response | At 1 m on axis: 46 Hz to 20 kHz � 3 dB |
| Maximum SPL | At 1 m: 124 dB continuous/130 dB peak |
| PTML (Peak Transient Mechanical Limit) | 141 dB |
| Sensitivity | At 1W @ 1 m: 98 dB SPL/100 Hz to 4 kHz |
| Nominal Impedance | 8 ?, each driver |
| Maximum Power Handling | 400 W continuous/1600 W peak |
| Dimensions (W x H x D) | Front: 20.25 x 30.25 x 15.1" (515 x 769 x 384 mm) Rear: 13.3 x 30.25 x 15.1" (338 x 769 x 384 mm) |
| Weight | 77 lb (35 kg) |
