XP POWER IE0503S Isolated Board Mount DC/DC Converter, 1kV Isolation, 1 Output, 1 W, 3.3 V, 300 mA
XP POWER IE0503S Isolated Board Mount DC/DC Converter, 1kV Isolation, 1 Output, 1 W, 3.3 V, 300 mA
Product details
| Output Power Max | 1W |
| Input Voltage DC Min | 4.5V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 11.68mm |
| Width | 6mm |
| Product Range | IE Series |
| DC / DC Converter Type | SIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 3.3V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed |
| Input Voltage DC Max | 5.5V |
| Output Current - Output 1 | 300mA |
| Height | 9.65mm |
Other details
| Brand | XP POWER |
| Part Number | IE0503S |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
