Traco Power TRN 1-2423SM Isolated Surface Mount DC/DC Converter ITE 2:1 1 W 2 Output 15 V 35 mA

The TRN 1SM series from Tracopower are 1W fully regulated, high performance DC to DC converters. These converters have wide 2: 1 input voltage range and come in a very compact SMD package (11.9mm x 11.3mm x 8mm).

• Nominal input voltage : 9VDC/12VDC/24VDC/48VDC
• Output voltage : 3.3VDC/5VDC/12VDC/15VDC/24VDC/±5VDC/±12VDC/±15VDC
• Maximum output current : 300mA/200mA/90mA/70mA/45mA/±100mA/±45mA/±35mA
• Efficiency up to 83%, PFM switching frequency is 100KHz minimum
• I/O isolation voltage (60sec) is 1600VDC
• Maximum I/O isolation capacitance is 75pF
• I/O isolation resistance is >1Gohm at 500VDC
• Ripple and noise (20MHz bandwidth) is 50mVp-p typical
• Short circuit protection
• Operating temperature range from -40°C to 90°C, 3-year product warranty

Other details

Brand	TRACO POWER
Part Number	TRN 1-2423SM
Quantity	Each
Technical Data Sheet EN
CAD Multiple Formats EN
