TRACO POWER TMLM 20115 AC/DC PCB Mount Power Supply (PSU), ITE, 1 Output, 20 W, 15 VDC, 1.33 A
TRACO POWER TMLM 20115 AC/DC PCB Mount Power Supply (PSU), ITE, 1 Output, 20 W, 15 VDC, 1.33 A
The TMLM 20115 is a 1-output 20W PCB mount AC/DC Power Module offers highest power density in a fully encapsulated module which can be soldered directly on to PCBs. The power module is ideal solution for all space critical applications. International safety approvals qualify the product for worldwide markets. SMD-technology and high efficiency guarantees a high reliability of these power supplies.
- Universal input
- Low ripple and noise
- Highest power density
- Fully encapsulated plastic case
- Short-circuit and overload protection
- 83% Typical efficiency
Applications
Power Management, Industrial, Commercial
Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
| Power Supply Applications: ITE |
| No. of Outputs: 1 Output |
| Output Power Max: 20W |
| Output Voltage - Output 1: 15VDC |
| Output Current - Output 1: 1.33A |
| Output Voltage - Output 2: - |
| Output Current - Output 2: - |
| Output Voltage - Output 3: - |
| Output Current - Output 3: - |
| Power Supply Output Type: Fixed |
| Input Voltage VAC: 90V AC to 264V AC |
| Width: 27.32mm |
| Height: 23.5mm |
| Depth: 52.5mm |
| Product Range: TMLM Series |
Other details
| Brand | TRACO POWER |
| Part Number | TMLM 20115 |
| Quantity | Each |
| Technical Data Sheet EN |  |
