TRACO POWER TIB 480-124 AC/DC DIN Rail Power Supply (PSU), ITE, 1 Output, 480 W, 24 VDC, 20 A

TIB 480-124 is a TIB 480 Series 480W AC/DC industrial power supply. This generation of DIN-rail power supply combines the most efficient circuit topology with optimized cost/performance ratio for industrial environments and for electrical control cabinets. It has a very high efficiency which allows a very slim package design. The case offers the potentially useful feature to fix the DIN-rail clip to the side wall for the mounting inside flat panels. Over a period of minimum 4 seconds they can operate with a boost power of 150%. The boost power facilitates the activation of stepper motors, solenoids or actuators. The units operate with a high power factor of up to 99% by active power factor correction which also keeps the input inrush current low. It comes with the safety standard approvals for IEC/EN 60950-1, UL 60950-1 and UL 508.

• Operating input voltage range from 85 to 264VAC (full range)
• Output voltage range of 24VDC (23.5 to 28.0VDC)
• Maximum output current is 20000mA
• Efficiency typically is 95%
• Slim profile, for DIN-rail mounting
• Power back immunity
• Operating temperature range from -40°C to +70°C
• Short circuit and overload protection
• 3-year product warranty
