TRACO POWER THD 10-2411N Isolated Through Hole DC/DC Converter, ITE, 2:1, 10 W, 1 Output, 5.1 V, 2 A

The THD 10-2411N from Tracopower is a THD 10N series 10W DC to DC converter in 24 pin DIP package. The THD 10N series is designed for an optimized cost/performance ratio of DC to DC converters with output power of 10 Watt. They come with an internal EMI-filter to meet EN55022, class A without external components. General features like no minimum load requirement, overload protection and high efficiency make these converters easy to design in. With the popular DIP-24 standard package they are also a drop in replacement for many cost critical applications.

• Input voltage range from 18VDC to 36VDC (24VDC nominal)
• Output voltage is 5.1VDC
• Maximum output current is 2000mA
• Typical efficiency is 85%
• I/O isolation voltage is 1500VDC, maximum I/O isolation capacitance is 1500pF
• I/O isolation resistance is >1000Mohm at (500VDC)
• Input current at no load is 15mA typical
• Switching frequency is 330KHz, wide 2:1 input voltage range
• Operating temperature range from -40°C to +85°C
• UL/cUL 60950-1, IEC/EN 60950-1 safety standards

Applications

Industrial
