Seeed Studio 106990290 Lipo Rider Plus Board Battery Charger Power Management -

Lipo rider plus is a fast charger and a Strong PowerBoost, supports up to 5V/2A charging current, boost output integration, output up to 5V/2.4A, can also output 3.3V /250mA. The 3.3V output is normally on, and the 5V output supports IO control or manual switch, which means you can use 3.3V to supply power for a microcontroller and use the I/O of this microcontroller to control the 5V output, totally programmable.

• Up to 5V/2A charging current - USB type C
• Up to 5V/2.4A output current - USB type A
• Provides 3.3V/250mA output -  pin header
• Support for shutdown output (IO control/manual switch)
• On-board charge status indicator LED + on-board 4-segment power indicator LED
• Ultra-small size of 2.5cm x 4.1cm
• Single-layer layout easy mount

Other details

Brand	SEEED STUDIO
Part Number	106990290
Quantity	Each
Technical Data Sheet EN
