RECOM POWER R-7815-0.5 Non Isolated POL DC/DC Converter, Switching, Fixed, SIP, Through Hole, 1 Output, 7.5 W, 15 V
RECOM POWER R-7815-0.5 Non Isolated POL DC/DC Converter, Switching, Fixed, SIP, Through Hole, 1 Output, 7.5 W, 15 V
The R-7815-0.5 is a 1-output Non-isolated Switching Regulator with non standard output voltage and wide input range. The R-78XX series high efficiency low profile regulator is ideally suited to replace 78xx linear regulators and is pin compatible. The efficiency of up to 97% means that very little energy is wasted as heat so there is no need for any heat sinks with their additional space and mounting costs. Low ripple and noise figures, overload and over-temperature protection round off the specifications of this versatile converter series.
- Efficiency up to 97%
- Short-circuit protection, thermal shutdown
- Non standard outputs available as specials
- Low ripple and noise
Applications
Power Management
Product details
| Output Power Max | 7.5W |
| Input Voltage DC Min | 18V |
| DC / DC Converter Mounting | Through Hole |
| Depth | 11.5mm |
| Width | 7.55mm |
| Product Range | R-78-0.5 Series |
| Output Current Max | 500mA |
| DC / DC Converter Type | SIP |
| Approvals & Standards | UL |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed |
| Output Voltage Nom. | 15V |
| Input Voltage DC Max | 32V |
| Height | 10.2mm |
Other details
| Brand | RECOM POWER |
| Part Number | R-7815-0.5 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
