MURATA POWER SOLUTIONS NMV1215SC Isolated Board Mount DC/DC Converter, 3kV Isolation, Fixed, 2 Output, 10.8 V, 13.2 V, 1 W, 15 V
MURATA POWER SOLUTIONS NMV1215SC Isolated Board Mount DC/DC Converter, 3kV Isolation, Fixed, 2 Output, 10.8 V, 13.2 V, 1 W, 15 V
Product details
| Output Power Max | 1W |
| Input Voltage DC Min | 10.8V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | -15V |
| Output Current - Output 2 | 33mA |
| Depth | 19.5mm |
| Width | 6mm |
| Product Range | NMV Series |
| DC / DC Converter Type | SIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 15V |
| Output Current - Output 3 | - |
| DC / DC Converter Output Type | Fixed |
| No. of Outputs | 2 Output |
| Input Voltage DC Max | 13.2V |
| Output Current - Output 1 | 34mA |
| Height | 10mm |
Other details
| Brand | MURATA POWER SOLUTIONS |
| Part Number | NMV1215SC |
| Quantity | Each |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
| Product Change Notice EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Original: $14.07
-70%$14.07
$4.22MURATA POWER SOLUTIONS NMV1215SC Isolated Board Mount DC/DC Converter, 3kV Isolation, Fixed, 2 Output, 10.8 V, 13.2 V, 1 W, 15 V
