MURATA POWER SOLUTIONS NME1212SC Isolated Board Mount DC/DC Converter, Fixed, 1 Output, 10.8 V, 13.2 V, 1 W, 12 V
MURATA POWER SOLUTIONS NME1212SC Isolated Board Mount DC/DC Converter, Fixed, 1 Output, 10.8 V, 13.2 V, 1 W, 12 V
The NME1212SC is a 1-output 1W board-mount isolated DC to DC Converter particularly suited to isolating and/or converting DC power rails. The galvanic isolation allows the device to be configured to provide an isolated negative rail in systems where only positive rails exist. Pin compatible with LME and NML series.
- 1kVDC Isolation
- Efficiency up to 80%
- 1.53W/cm³ Power density
- Footprint from 0.69cm²
- Industry standard pinout
- No heatsink required
- Internal SMD construction
- Fully encapsulated with toroidal magnetics
- No external components required
- MTTF up to 3.4 million hours
- PCB mounting
- -40 to +85°C Operating temperature range
Applications
Power Management
- :
- 1W
- :
- 10.8V
- :
- Through Hole
- :
- -
- :
- -
- :
- 11.48mm
- :
- 6mm
- :
- NME Series
- :
- SIP
- :
- -
- :
- -
- :
- 12V
- :
- -
- :
- Fixed
- :
- 1 Output
- :
- 13.2V
- :
- 83mA
- :
- 10mm
Product details
| Output Power Max | 1W |
| Input Voltage DC Min | 10.8V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 11.48mm |
| Width | 6mm |
| Product Range | NME Series |
| DC / DC Converter Type | SIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 12V |
| Output Current - Output 3 | - |
| DC / DC Converter Output Type | Fixed |
| No. of Outputs | 1 Output |
| Input Voltage DC Max | 13.2V |
| Output Current - Output 1 | 83mA |
| Height | 10mm |
Other details
| Brand | MURATA POWER SOLUTIONS |
| Part Number | NME1212SC |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
