Omega SHX-J-M SHX-J-M Thermocouple Connector Plug Type J Miniature 2 Positions Ansi SHX Series

SHX sub miniature connector is ideal for use with fine gauge thermocouple wires in applications where high temperatures are required. The SHX connector is permanently dot-coded to conform to ANSI and OMEGA standards; for applications such as high vacuum furnaces where contamination would adversely affect the process. Two-piece ceramic construction assures long life, while the oversized terminal screws allow for easy wiring.

• Glazed connector with colour coded dot
• Type J male connector
• Extra heavy duty ceramic construction
• One-piece body with removable cap design
• Oversized terminal screws for easy wiring
• Accepts stranded or solid wire up to size 20AWG
• Ceramic body temperature rating is 650°C (1200°F)

Other details

Brand	OMEGA
Part Number	SHX-J-M
Quantity	Each
Technical Data Sheet EN
