Molex 90136-2205 Pin Header Wire-to-Board 2.54 mm 1 Rows 5 Contacts Through Hole Right Angle
Molex 90136-2205 Pin Header Wire-to-Board 2.54 mm 1 Rows 5 Contacts Through Hole Right Angle
Product details
| Connector Systems | Wire-to-Board |
| Pitch Spacing | 2.54mm |
| No. of Rows | 1Rows |
| No. of Contacts | 5Contacts |
| Contact Termination Type | Through Hole Right Angle |
| Product Range | C-Grid III 90136 Series |
| Connector Shroud | Shrouded |
| Contact Material | Brass |
| Contact Plating | Gold Plated Contacts |
Other details
| Brand | MOLEX |
| Part Number | 90136-2205 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
| Drawing EN | |
| CAD Multiple Formats EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
