METZ CONNECT AST1350204 Wire-To-Board Terminal Block, 5 mm, 2 Ways, 28 AWG, 14 AWG, 2.5 mm², Push In Lock
METZ CONNECT AST1350204 Wire-To-Board Terminal Block, 5 mm, 2 Ways, 28 AWG, 14 AWG, 2.5 mm², Push In Lock
The AST1350204 is a 2-pole grey wire-to-board spring clamp solderable Terminal Block with through-hole 45° direction of connection. It is fittable without loss of poles and has 5mm centreline. It has tin-plated CuZn contact with steel spring and a PA 66 insulator.
- IP20 Protection
- CTI600 Insulating material class
- -40 to 105°C Operating temperature range
Applications
Industrial
Product details
| Pitch Spacing: 5mm |
| No. of Positions: 2Ways |
| Wire Size AWG Min: 28AWG |
| Wire Size AWG Max: 14AWG |
| Conductor Area CSA: 2.5mm² |
| Wire Connection Method: Push In Lock |
| Rated Current: 24A |
| Rated Voltage: 250V |
| Block Orientation: Through Hole 45° |
| Product Range: - |
Other details
| Brand | METZ CONNECT |
| Part Number | AST1350204 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
