Lilliput Q28-8K Overview

This V-mount version of the Q28 28" 8K 12G-SDI Production Monitor with Carry Case from Lilliput belongs to the flagship lineup of monitors engineered to handle and process 8K video input signals. It seamlessly integrates four 12G-SDI input feeds through the BNC connectors located at the rear of the unit.

Adhering to the ST2082-12 video protocol, it amalgamates these feeds to generate an 8K60 video signal, which is then displayed on its 3840 x 2160 panel. Boasting additional features such as REC. 709 and DCI-P3 color space support, 3D LUT compatibility, remote control via LAN connection, Multiview and Quad-Split functionalities, and an optional 12G-SFP connection, the Q28 offers extensive monitoring capabilities within a user-friendly system.

Items Included

  • Lilliput Q28 28" 8K 12G-SDI Production Monitor with Carry Case (V-Mount)
  • 15 VDC Power Adapter
  • V-Mount Plate
  • VESA Mount Plate
  • Set of Base Brackets
  • USB Flash Drive
  • Carry Case
  • Limited 1-Year Manufacturer Warranty

Additional Resources

    Lilliput Q28-8K Specs

    Key Specs
    Display Size
    28.00" / 71.1 cm
    Native Resolution
    3840 x 2160
    Touchscreen
    No
    HDR Support
    Yes
    Video I/O
    4x BNC (12G-SDI) Input
    1x HDMI 2.0 Input
    4x BNC (12G-SDI) Output
    1x HDMI 2.0 Output
    1x SFP+ (12G-SDI) Input
    Media/Memory Card Slot
    No
    Video Format
    Fiber/HDMI
    DCI 4K: 60/50/30/25/24
    UHD 4K: 60/50/30/25/24
    1080p: 60/50/30/25/24
    1080i: 60/50
    720p: 60/50
    SDI
    8K: 60/50/30/25/24
    DCI 4K: 60/50/30/25/24
    UHD 4K: 60/50/30/25/24
    1080p: 60/50/25/24
    1080PsF: 30/25/24
    1080i: 60/50
    720p: 60/50
    Battery
    1x V-Mount on Included, Interchangeable Plate
    Power Consumption
    65 W
    Display
    Panel Type
    LCD
    Display Size
    28.00" / 71.1 cm
    Native Resolution
    3840 x 2160
    Aspect Ratio
    16:9
    Viewing Angle
    Horizontal: 178°
    Vertical: 178°
    Touchscreen
    No
    Maximum Brightness
    300 nits / cd/m2
    Contrast Ratio
    1000:1
    HDR Support
    Yes
    Color Gamut
    90% Rec. 709
    90% DCI-P3
    Image Controls
    Check Field, Color Temperature Selection, False Color, Focus Peaking, H/V Delay, Histogram, Pixel Zoom, Pixel-to-Pixel Zoom, Vectorscope, Waveform
    Inputs/Outputs
    Video I/O
    4x BNC (12G-SDI) Input
    1x HDMI 2.0 Input
    4x BNC (12G-SDI) Output
    1x HDMI 2.0 Output
    1x SFP+ (12G-SDI) Input
    Embedded Audio
    HDMI/SDI
    Audio I/O
    1x 1/8" / 3.5 mm Headphone Output
    Built-In Speaker
    Stereo
    Power I/O
    1x XLR 4-Pin (24 VDC) Input
    Other I/O
    1x RJ45 (LAN) Input
    1x RJ45 (GPI) Input
    1x RJ45 (RS-422) Input
    1x RJ45 (RS-422) Output
    Media/Memory Card Slot
    No
    Wireless
    Wi-Fi
    No
    Bluetooth
    No
    Mobile App Compatible
    No
    Format Support
    Video Format
    Fiber/HDMI
    DCI 4K: 60/50/30/25/24
    UHD 4K: 60/50/30/25/24
    1080p: 60/50/30/25/24
    1080i: 60/50
    720p: 60/50
    SDI
    8K: 60/50/30/25/24
    DCI 4K: 60/50/30/25/24
    UHD 4K: 60/50/30/25/24
    1080p: 60/50/25/24
    1080PsF: 30/25/24
    1080i: 60/50
    720p: 60/50
    Power
    Input Power
    12 to 24 VDC
    Battery
    1x V-Mount on Included, Interchangeable Plate
    Power Consumption
    65 W
    General
    Operating Conditions
    32 to 122°F / 0 to 50°C
    Storage Conditions
    -4 to 140°F / -20 to 60°C
    Dimensions
    25.1 x 16.3 x 1.8" / 638 x 414.3 x 45.7 mm
    Weight
    19.0 lb / 8.6 kg
    Packaging Info
    Package Weight
    46.975 lb
    Box Dimensions (LxWxH)
    32.2 x 22.4 x 10.3"

    All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
