Harwin M22-2035005 M22-2035005 Pin Header Right Angle Wire-to-Board 2 mm 1 Rows 50 Contacts Through Hole M22

Harwin M22-2035005 M22-2035005 Pin Header Right Angle Wire-to-Board 2 mm 1 Rows 50 Contacts Through Hole M22

The M22-2035005 is a 50-contact 2mm male SIL Pin Header with gold plated phosphor bronze contacts, gold plated termination and black UL94V-0 polyamide (nylon) 6T housing. The M22 series connector has 3.4mm PC tail, horizontal connector orientation and PC tail/through board connection type. It is suitable for use with 0.5mm square mating pin size.
  • 1A Current rating
  • 650VAC Voltage proof
  • 20mR Maximum contact resistance
  • 1000MR (initial) Minimum insulation resistance
  • 300 operations Durability
Applications

Commercial, Industrial

Other details

Brand HARWIN
Part Number M22-2035005
Quantity Each
3D Product Image EN Download technical document - datasheet - Tanotis India
Drawing EN Download technical document - datasheet - Tanotis India
Manufacturer Catalogue EN Download technical document - datasheet - Tanotis India

All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
