Fujinon 1.5MP 50mm C Mount Lens with Anti-Shock & Anti-Vibration Technology for 2/3" Sensors
Fujinon 1.5MP 50mm C Mount Lens with Anti-Shock & Anti-Vibration Technology for 2/3" Sensors
Fujinon HF50HA-1S Overview
The Fujinon 1.5MP 50mm C Mount Lens with Anti-Shock & Anti-Vibration Technology is designed to provide low distortion, high-quality image capture in machine vision applications. The compact lens covers 2/3" sensors and features a fast f/2.3 aperture that ensures clear images in low light environments. Focus and iris adjustment are manual, and individual focus/iris lock tabs are provided to maintain set positions over time. Built-in anti-shock and anti-vibration technology highly reduces the need for these tabs because their primary purpose was to protect against changes caused by vibration.
The anti-shock and anti-vibration technology helps keep both the mechanical and optical elements of the lens in their original positions to maintain consistent image quality in harsh environments that produce a lot of vibration. The new feature also helps protect the lens from damage caused by accidental falls. The lens is complete with a robust build, metal mount, and smooth focus and iris ring rotation.
Key Features
- Low distortion, high-quality image capture for machine vision applications
- Covers 2/3" sensors
- Fast f/2.3 aperture
- Manual focus and iris adjustment
- Individual focus and iris lock tabs
- Built-in anti-shock and anti-vibration technology for consistent image quality
- Metal mount
- Smooth focus and iris ring rotation
In the Box
- Fujinon 1.5MP 50mm C Mount Lens with Anti-Shock & Anti-Vibration Technology for 2/3" Sensors
- Limited 2-Year Warranty
Fujinon HF50HA-1S Specs
| Lens Mount | C |
| Sensor Compatibility | 2/3" |
| Focal Length | 50mm |
| Aperture | f/2.3 to 22 |
| Angle of View | 2/3" Sensor Horizontal: 7.6 to 10.1° |
| Minimum Object Distance | 19.69" / 50 cm |
| Focus Type | Manual Focus |
| Iris Type | Manual |
| Distortion | 2/3": 0.06% |
| Filter Thread | M25.5 x 0.5 mm |
| Dimensions (ø x L) | 1.16 x 1.16" / 29.5 x 29.5 mm |
| Weight | 1.59 oz / 45 g |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
