Comprehensive Cat6 550 MHz Shielded Solid LAN Cable (White / 1,000')
- Cat6 Standard
- 1,000' Length
- Four Pairs of Shielded Twisted Wire
- 550 MHz Transmission Speed
- Designed for Fast & Gigabit Ethernet
- 24 AWG Stranded Bare Copper Conductors
Designed for 550 MHz high-speed data applications, such as 100BASE -TX, 100BASE-VG, and 155 ATM, as well as high-speed applications, such as 622 ATM, Wideband, Ethernet 1000BASE-T, and emerging applications with anticipated data rates to 3.2 Gbps, the white Cat6 550 MHz Shielded Solid LAN Cable from Comprehensive comes in 1,000'�lengths marked off in one foot increments; so you can make cables of any length as needed. It is packaged in a simple pull-through designed box to keep this bulk cable free of kinks and knots. It follows the Cat6 standard and has been constructed using four shield twisted pairs wrapped in a sturdy PVC (polyvinyl chloride) jacket that perform well in noisy environments, feature strong attenuation and crosstalk characteristics, as well as 24 AWG solid bare copper conductors.
General Features
- High-performance data communications cable for noisy environments
- Suitable for 550 MHz high-speed data applications, Gigabit Ethernet, fast Ethernet, and 155 Mbps TP-PMD/CDDI
- Cat6 Shielded Twisted Pair (FTP) cable
- The cable has four shielded twisted pairs that are easily identifiable as they are color-striped
- 24 AWG solid bare copper conductors
- Good attenuation and crosstalk characteristics
- Exceeds EIA/TIA 568 B.2-1, UL, CSA, and ISO/IEC 11801 specifications
- UL/cUL or ETL listed
- Sequential foot markers
- Limited Lifetime Warranty
| Conductors | 4 Twisted Pairs 24 AWG Shielded bare copper solid cable |
| Bandwidth | Supports voice/data/video distribution applications up to 550 MHz |
| Standards | Meets all Cat6 TIA/EIA standards, Verified to EIA/TIA 568B.2 |
| Conductor DC Resistance | 9.8 Ohms; at 328'/ 100 m maximum |
| UL Rating | CMR |
| Jacket | PVC (white) |
| Electrical | Temperature rating: 167�F / 75�C Spark test: 2,000 VAC/0.15 sec minimum Dielectric strength: 750 VAC / 1 sec minimum Insulation resistance: PE: 500 VDC, 1500 MW / 328' / 100 m minimum at 68�F / 20�C |
| Capacitance | Mutual Capacitance: 5.6 nF / 328' / 100 m, maximum Pair to ground Unbalance: 330 pF / 328' / 100 m, maximum DC Resistance: 9.38 Ohms / 328' / 100 m at 68�F / 20�C maximum DC Resistance Unbalance: 5%, maximum Impedance: 100 �15 Ohms at 100 to 350 MHz |
| Dimensions | Length: 1,000' / 304.8 m Outer Diameter: 0.25" / 6.30 mm |
| Weight | 27.00 lb (12.24 kg) |
| Packaging Info | |
|---|---|
| Package Weight | 31.75 lb |
| Box Dimensions (LxWxH) | 15.6 x 15.5 x 8.7" |
Original: $972.81
-70%$972.81
$291.84Comprehensive Cat6 550 MHz Shielded Solid LAN Cable (White / 1,000')
- Cat6 Standard
- 1,000' Length
- Four Pairs of Shielded Twisted Wire
- 550 MHz Transmission Speed
- Designed for Fast & Gigabit Ethernet
- 24 AWG Stranded Bare Copper Conductors
Designed for 550 MHz high-speed data applications, such as 100BASE -TX, 100BASE-VG, and 155 ATM, as well as high-speed applications, such as 622 ATM, Wideband, Ethernet 1000BASE-T, and emerging applications with anticipated data rates to 3.2 Gbps, the white Cat6 550 MHz Shielded Solid LAN Cable from Comprehensive comes in 1,000'�lengths marked off in one foot increments; so you can make cables of any length as needed. It is packaged in a simple pull-through designed box to keep this bulk cable free of kinks and knots. It follows the Cat6 standard and has been constructed using four shield twisted pairs wrapped in a sturdy PVC (polyvinyl chloride) jacket that perform well in noisy environments, feature strong attenuation and crosstalk characteristics, as well as 24 AWG solid bare copper conductors.
General Features
- High-performance data communications cable for noisy environments
- Suitable for 550 MHz high-speed data applications, Gigabit Ethernet, fast Ethernet, and 155 Mbps TP-PMD/CDDI
- Cat6 Shielded Twisted Pair (FTP) cable
- The cable has four shielded twisted pairs that are easily identifiable as they are color-striped
- 24 AWG solid bare copper conductors
- Good attenuation and crosstalk characteristics
- Exceeds EIA/TIA 568 B.2-1, UL, CSA, and ISO/IEC 11801 specifications
- UL/cUL or ETL listed
- Sequential foot markers
- Limited Lifetime Warranty
| Conductors | 4 Twisted Pairs 24 AWG Shielded bare copper solid cable |
| Bandwidth | Supports voice/data/video distribution applications up to 550 MHz |
| Standards | Meets all Cat6 TIA/EIA standards, Verified to EIA/TIA 568B.2 |
| Conductor DC Resistance | 9.8 Ohms; at 328'/ 100 m maximum |
| UL Rating | CMR |
| Jacket | PVC (white) |
| Electrical | Temperature rating: 167�F / 75�C Spark test: 2,000 VAC/0.15 sec minimum Dielectric strength: 750 VAC / 1 sec minimum Insulation resistance: PE: 500 VDC, 1500 MW / 328' / 100 m minimum at 68�F / 20�C |
| Capacitance | Mutual Capacitance: 5.6 nF / 328' / 100 m, maximum Pair to ground Unbalance: 330 pF / 328' / 100 m, maximum DC Resistance: 9.38 Ohms / 328' / 100 m at 68�F / 20�C maximum DC Resistance Unbalance: 5%, maximum Impedance: 100 �15 Ohms at 100 to 350 MHz |
| Dimensions | Length: 1,000' / 304.8 m Outer Diameter: 0.25" / 6.30 mm |
| Weight | 27.00 lb (12.24 kg) |
| Packaging Info | |
|---|---|
| Package Weight | 31.75 lb |
| Box Dimensions (LxWxH) | 15.6 x 15.5 x 8.7" |
