Canare L-4E6S Star Quad Microphone Cable (656', White)
- Spool of Cable 656' in Length
- Standard Diameter, 21 AWG
- Fits All XLR-Type Audio Connectors
- Rejects EMI and RFI Interference
- Cross Linked PE Insulation
- For Use with Handheld Mics & PA Systems
Colored in a White matte jacket, Canare 's L-4E6S provides 656' of standard diameter, 21 AWG cable to fit within in all kinds of XLR-type audio connection points. It's designed to be utilized with PA systems and handheld applications, and features 40 separate strands in each conductor to eliminate breakage, making the cable quite flexible.
- Braided copper shield
- Flexible in extremely cold weather
- Cross linked PE insulation
- Reduced handling noise
- Rejects EMI and RFI
- White matte color jacket
In the Box
Canare L-4E6S Star Quad Microphone Cable (656', White)
- 1-Year Warranty
| Applications | Microphones, portable applications, audio rack wiring, PA systems, and audio patch cords |
| Outer Diameter | 0.2" / 6 mm, nominal |
| PVC Jacket Thickness | 0.04" / 1.1 mm, nominal |
| Number of Conductors | 4 (2 blue and 2 white) |
| Insulation | Type: IPE Thickness: 0.6" / 15.7 mm Dielectric Strength: 500 VAC/minute Insulation Resistance: 1,000 MOhms per 3' / 0.9 m |
| Conductor | AWG (AC): 24 (40/3.15 quantity/mm) Cross Sectional Area: 310 mm 2 AWG (Quad): 21 Effective AWG of combined twin conductors |
| Pitch Twist Quad | 0.8" / 20 mm |
| Shield Coverage | >95% TAC Braid |
| Conductor D.C.R. | <29.9 Ohms/1,000' / <9.8 Ohms/100 m |
| Shield D.C.R | <9.1 Ohms /1,000' / <3 Ohms/100 m |
| Nominal Capacitance | Between Twin Blue & White Conductors: 46 pF/ft / 150 pF/m Between Conductors & Shield: 57 pF/ft / 185 pF/m |
| Nominal Impedance | 44 Ohms |
| Nominal Attenuation | 0.9 V/1,000' / 0.3 V/100 m |
| Group Delay Time | 1.80 ns/ft / 5.9 ns/m |
| Brittle Point | -56�F / -49�C |
| Length | 656' / 200 m |
| Weight | 24 lb / 11 kg |
| Packaging Info | |
|---|---|
| Package Weight | 23.55 lb |
| Box Dimensions (LxWxH) | 11.5 x 11.1 x 9.0" |
