BOURNS SRN8040-220M Surface Mount Power Inductor, SRN8040 Series, 22 �H, 2.2 A, 2.2 A, Shielded, 0.1 ohm
BOURNS SRN8040-220M Surface Mount Power Inductor, SRN8040 Series, 22 �H, 2.2 A, 2.2 A, Shielded, 0.1 ohm
Product details
| Inductance Tolerance | � 20% |
| RMS Current (Irms) | 2.2A |
| Saturation Current (Isat) | 2.2A |
| Power Inductor Case | 8mm x 8mm x 4mm |
| Inductance | 22�H |
| Inductor Construction | Shielded |
| Product Range | SRN8040 Series |
| DC Resistance Max | 0.1ohm |
| Packaging | Cut Tape |
Other details
| Brand | BOURNS |
| Part Number | SRN8040-220M |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| Technical Data Sheet EN | |
| 3D Product Image EN | |
| Product Change Notice EN | |
