AVMATRIX Shark H4 PLUS 4-Channel HDMI Video Switcher with 10.1" IPS Display
AVMATRIX SHARK H4 PLUS Overview
By Photo's
Jennifer Hahn
Switch up to four HDMI video inputs while monitoring the program feed with the portable Shark H4 PLUS 4-Channel HDMI Video Switcher with 10.1" IPS Display from AVMATRIX. This model features a folding design with a 10.1" IPS LCD screen on the lid. Use the USB-C output together with your computer for capture and live streaming using your computer, and record directly from the unit using the USB-A output or SD card slot.
This compact switcher supports up to 1080p60 video input and output with embedded audio, and it offers audio mixing using the two analog stereo 3.5mm mic/line inputs and embedded audio. Switcher control options include push buttons, a T-bar, and IP control via the LAN port.
USB Capture & Streaming
Built-in USB-C port can be used to connect the switcher to a computer for USB capture and streaming using software like OBS, Skype, Teams, VLC, Zoom, or vMix.
10.1" Full HD IPS Display
The switcher features a 10.1" 1920 x 1080 IPS LCD display that provides multiview, preview, program, audio meters, time clock, and menu configuration.
USB and SD Card Recording
Record your program to an SSD or flash drive in MP4 format using the USB-A recording output, or utilize an optional SD card for in the built-in SD card recording slot.
Live Stream via Ethernet
The LAN port supports IP streaming via RTMP or SRT protocols, allowing you to easily live stream to popular platforms such as YouTube, Skype, Facebook, Twitch, and more.
Software Remote Control
Offers easy control of all settings and operations through the control software, including transitions, audio configurations, media management, and more.
Multiple Interfaces
Multiple interfaces include four HDMI inputs, Program outputs, multiview output, audio inputs, streaming, and recording ports. The outputs can all be configured to pass input, preview, program, clean program, and color bars.
Other Features
- Enhanced chroma key
- Professional audio mixer with embedded and analog audio inputs
- Import up to 39 default patterns, 16 imported images, 16 captured images, and two color generators via USB
- PiP, PoP, logo overlay, transition effects
Applications
- Broadcast
- Education
- Conference
- Social media/vlogging
- Live sports
- House of worship
- Live events
Items Included
- AVMATRIX Shark H4 PLUS 4-Channel HDMI Video Switcher with 10.1" IPS Display
- 12V Power Supply
- USB-A to USB-C Cable
- Tally Connector
- Limited 3-Year Manufacturer Warranty
Additional Resources
AVMATRIX SHARK H4 PLUS Specs
| Available M/E Layers |
2 M/E
|
| Effect Types |
1x Luma Key
|
| Downstream Keys |
1x Chroma
1x Luma |
| Generators |
1x Pattern
2x Color |
| Audio Mixing |
2-Channel Mixing
|
Processing
| Switching Type |
Pushbutton, Software, T-Bar
|
| Processing Resolution |
1080p at 23.98/24/25/29.97/30/50/59.94/60
|
| Color Processing |
RGB
YCbCr |
Input
| Number of Video Input Sources |
4
|
| Video Inputs |
4x HDMI Female
|
| Input Video Format |
HDMI
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps |
| Audio Inputs |
2x 1/8" / 3.5 mm TRS Stereo Analog Female
|
| Input Audio Format |
Analog
|
| Embedded Audio Input |
HDMI: 2-Channel
|
Output
| Video Output Channels |
5
|
| Video Outputs |
2x HDMI Female (Program)
1x HDMI Female (Monitor) 1x USB-C (USB Video) Female (Program) 1x USB-A (USB Video) Female (Program) |
| Output Video Format |
HDMI
1080p at 24/25/30/50/60 fps 1080i at 50/60 fps USB-C 1080p at 60 fps |
| Audio Outputs |
1x 1/8" / 3.5 mm TRS Stereo Analog Female (Loop Output)
|
| Embedded Audio Output |
HDMI
USB-C |
| Multiview Output |
4-Way Multiview via HDMI
|
| Monitor Output |
1x HDMI
|
Connectivity
| Other I/O |
1x RJ45 LAN Input
1x DE-15/DB-15 Tally Input/Output 1x USB-A Input |
| HDCP Support |
No
|
| IP Video |
1920 x 1080 Encoding
|
| Transport Protocols |
RTMP, RTMPS, SRT
|
| Simultaneous Streams |
1 Streams
|
| Recording Media |
1x SD (Unspecified Type)
|
Display
| Display Size |
10.1"
|
| Screen Resolution |
1920 x 1080
|
| Processor |
Not Specified by Manufacturer
|
| Wi-Fi |
Yes
|
| Bluetooth |
Yes
|
| Power I/O |
1x Barrel (12 VDC at 1.7 A) Input
|
| Power Consumption |
Device: 20.4 W
|
General
| Operating Conditions |
-4 to 122°F / -20 to 50°C
|
| Dimensions |
10.29 x 7.63 x 2.3" / 26.14 x 19.39 x 5.8 cm
|
| Weight |
3.81 lb / 1.73 kg
|
Packaging Info
| Package Weight |
4.985 lb
|
| Box Dimensions (LxWxH) |
12.3 x 10.6 x 4.6"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
